Engineered for strength and efficiency, our heavy duty pallet rack is ideal forwarehouses, distribution centers and industrial spaces. Made from reinforced steel
with adjustable beam levels, it supports heavy loads and optimizes your storage footprint. Easy assembly, modular expansion and long-lasting performance ensure
maximum return on your storage investment.
Heavy Duty Shelving Features
A rigid, durable, versatile and economical racking system — the most widely used solution for
palletized storage of virtually any goods
*Rigid structure, durable, versatile and economical — the most widely used storage system for
different types of cargo
Wide range of racking heights, depths, lengths and load capacities to match your exact storage needs
*Fully adjustable beam level height — reposition in seconds as your inventory changes
*Very easy to install and dismantle; no special tools or welding required on site.
*Rapid handling and direct access to almost every type of goods on the floor
*Maximizes space use in any storeroom layout while retaining optimum product accessibility
*High strength and rigidity prevent compression and impact damage to stored goods
*Available with powder-coated or hot-dip galvanized finish for indoor and humid/cold-room use.
Boltless Hook Connection
The beam-to-upright connection uses a proven snap-in hook design — installation, dismantling and
level adjustment are all tool-free and take seconds.
Robust Upright Frames
Uprights are laser-cut and punched from high-strength Q235 steel, welded with horizontal and
diagonal bracing for a rigid, long-lasting load-bearing frame.
Widened Base Plates
Enlarged foot plates can be fixed to the floor with expansion bolts or left free-standing — installed
exactly the way your facility requires.
FLEXIBLE LAYOUT
Main Frames & Auxiliary Frames
Configure your racking run the smart way. Main frames stand alone; auxiliary frames share an
upright and link on to save cost and floor space.
Build long rows at lower cost
Main Frame (double-sided upright): upright frames on both sides — it stands independently
and can be used on its own.
Auxiliary Frame (single-sided upright): shares the rear upright of the main frame — it must be
connected to a main frame, but cuts steel cost per bay by roughly 20%.
Mixing main and auxiliary frames is how warehouses turn a single row into an entire block of
dense, palletized storage — without wasting a centimeter of aisle
Four Reasons Warehouses Choose Our Racking
Heavy Duty Pallet Rack Technical Specifications
| Product name | Heavy Duty Pallet Rack System |
| Material | High grade Q235B Steel |
| Specification of rack | Length:Up to 3600mm
Depth:700-1200mm Height:Up to 12,000mm warehouse pallet racking Standard size:L2500*D1000*H3500mm,customized size is available |
| Long span rack shelving Loading capacity | Up to 4,000 kgs UDL/level |
| Surface treatment | Powder Coating Finishing. |
| Upright specification | 90*60*1.8mm |
| Beam Specification | 120*45*1.5mm |
| layer | 2-8 layers(as you want) |
| Long span rack shelving Features | 1) Suitable for large amount of cargo with small number of kinds;
2) The height of each beam can be adjusted by pitch 75mm freely 3) Smart section design and high-quality steel 4) It facilitates the use of forklift trucks, electric reach trucks, narrow aisle turret trucks 5) It is the most widely used design of the storage system 6) warehouse storage rack Parts: Upright post, pallet support arm, wall spacer, horizontal bracing, row spacer, wire mesh deck, safety pins, steel footing plates etc. |
| Application | Warehouse,store,supermarket,4S shop, garage, widely used |
With superior load capacity, fast accessibility, and flexible configuration, our heavy duty shelving is a top choice for businesses seeking to improve warehouse efficiency and storage safety. Contact us today for a custom quote or professional layout advice.
